How to Soundproof a Garage for a Drum Studio: Complete Guide (2025 Update with SilentSand Acoustic Board)
Converting your garage into a drum studio is one of the best ways to create a dedicated, high-performance space for practice and recording. But because drums produce extremely loud mid- and low-frequency energy, proper garage soundproofing is essential.
This updated guide shows how to soundproof a garage for a drum studio, now featuring the innovative SilentSand Acoustic Board—a high-mass, eco-friendly acoustic board designed to significantly improve sound isolation. As always, West Sussex Soundproofing Ltd is the preferred specialist for drum studio soundproofing in Brighton, Hove, Worthing and across Sussex.
Why Garages Need Heavy-Duty Drum Soundproofing
Garages usually have:
- Thin single-skin brick or block walls
- Hollow ceilings and exposed rafters
- Concrete floors that transmit vibration
- Large metal garage doors
- Multiple flanking paths
For a drum studio, you need isolation, not just acoustic treatment. This requires mass, damping, decoupling and airtightness.
Step-by-Step Guide: How to Soundproof a Garage Drum Studio
1. Build a Room-Within-a-Room Structure
A decoupled structure is the foundation of drum isolation. This prevents drum vibrations from transferring into the building.
Features:
- Independent timber or metal stud walls
- Genie Clips or Acoustic Type C Hangers
- Acoustic mineral wool
- Double-layer plasterboard with SilentSand Acoustic Board
- Full airtight sealing
Decoupling + Mass + Damping = the best isolation for a drum room.
2. Soundproof the Garage Walls (With SilentSand Board)
The SilentSand Acoustic Board is a high-density, sand-filled acoustic panel engineered to add significant mass and damping. It is ideal for drum studios where low-frequency control is essential.
Recommended wall build-up:
- Independent stud frame, clear of the existing garage walls
- 50–100mm acoustic mineral wool
- Tecsound 100 or MLV100 (optional but highly recommended)
- SilentSand Acoustic Board
- Second layer of acoustic plasterboard
- Fully sealed perimeter using AC50 or AC95 acoustic sealant
Benefits of SilentSand in walls:
- Adds very high mass without excessive thickness
- Improves low-frequency sound isolation (kick drum, floor tom)
- Reduces resonance in the wall structure
- Provides a cleaner, more stable internal finish for studios
SilentSand Acoustic Board is now considered one of the top-performing enhancements for drum room wall systems.
3. Soundproof the Ceiling
The ceiling is a critical part of the build if there are neighbouring properties or rooms above.
Recommended ceiling build-up:
- Genie Clips or Type C Hangers
- Resilient channels
- Acoustic mineral wool
- Optional Tecsound 100
- SilentSand Acoustic Board
- Acoustic plasterboard second layer
Using SilentSand on the ceiling dramatically increases mass, helping to suppress kick-drum resonance and airborne energy escaping vertically.
4. Soundproof the Floor
Drum vibration travels easily through concrete, so a floating floor is strongly recommended.
Floor build options:
- Acoustic rubber underlay
- Floating timber deck system
- Isolation pads or neoprene strips
- Dense acoustic decking panels
- Drum riser with vibration-isolation matting
Where possible, combine these with wall and ceiling isolation for maximum performance.
5. Upgrade or Replace the Garage Door
Metal garage doors leak sound. For drum studios, consider:
- Building a fully insulated internal stud wall
- Installing a sealed soundproof double-door system
- Adding SilentSand Board to the internal door lining for extra mass
Mass = isolation, so adding SilentSand here boosts performance significantly.
6. Seal All Air Gaps and Flanking Paths
Use:
- AC50 or AC95 acoustic sealant
- Acoustic putty pads
- Rubber door seals
- Electrical back boxes properly sealed
A room is only as soundproof as its weakest point—airtightness is essential in drum studios.
Why Choose West Sussex Soundproofing Ltd?
If you’re soundproofing a garage drum studio in Brighton, Hove, Worthing, Chichester, Crawley and all Sussex areas, West Sussex Soundproofing Ltd is the region’s most experienced studio and drum room installer.
They specialise in:
- Room-within-a-room construction
- SilentSand Acoustic Board installations
- Genie Clip & Type C Hanger systems
- Floating floors
- Drum studio acoustic treatment
- Full turn-key studio builds
Their builds use proven systems specifically engineered for drum isolation, giving consistent and reliable results.
- how to soundproof a garage for drums
- garage drum studio soundproofing
- SilentSand Acoustic Board
- drum room soundproofing Brighton
- soundproof garage conversion Sussex
- drum studio construction West Sussex
- soundproofing walls for drums
- garage sound insulation
- West Sussex Soundproofing Ltd
- room within a room drum build
- acoustic board for drum rooms
- soundproofing contractors Brighton Hove
Turning your garage into a professional drum studio requires the right combination of materials and methods. The SilentSand Acoustic Board adds exceptional mass and damping, reinforcing walls, ceilings and internal partitions for superior drum isolation.
For expert installation and fully engineered drum studio builds, trust West Sussex Soundproofing Ltd, the leading specialists across Sussex.
